Product

RD350A

RD350A
Location:China
Business Type:Manufacturer, Exporter
Brands:RONGHUA
Minimum order quantity:
Price:Consultation
Delivery time:By contract
Payment method:L/C D/A T/T M/T D/D

[email protected]


Details

Description Video
model RD350A
Appearance table mode
color  white and orange
work speed 2speed opition
automatic paper length measurement ×
free Indentation
cover Identation  ×
equal part Identation  ×
binding Identation  ×
operate display  Color touch screen
display interface LCD
display definition  standard definition
counting mode positive count
user mode(indentation data storage) 32 groups
maximum feed size 3000×330mm
minimum feed size 60X65mm
creasing kinfe adapts to weight/thickness of paper  80g~450g
perfoat knife adapts to weight/thickness of paper  80g~250g
paper type tectorial membrance,spraying-film,copperplate paper
paper feed mode manual
feed direction paper feed in right side
feed table lengthening
feed table cappacity ×
receive table capacity 50mm
Indentation width gap 1.0mm
Indentation direction  Positive and negative are available
creasing /perforating precision  0.2mm
distance form the first mark to the paper hand 1mm
creasing speed  3000sheet/hour(50sheet/min)
maximum number of creasing /perforating tracks 32 group
power supply 220v/50hz
power   250W
power supply voltage adaptive range  AC 200V-240V
net weight 50KG
gross weight 60KG
dimension in using 1200×500×440mm
packing dimenstion 580×660×620mm
easily replaceable extraction tool
high precision programmable indentation setting
standard corsswise dotted blade
option engthways dotted blade X
automatic correction of paper deviation with differetn thickness
Indentation depth and skew adjustment
paper noise suction system  X
large capacity feed table X
automatic paper feed system X

Feedback

FAQ

1. How long can I get feedback after we send the inquiry?

We will reply to you within 12 hours on a working day.

2.Are you a direct manufacturer or trading company?

We have two of our own casting foundries and one CNC machining factory. We also have our own international sales department. We produce and sell it all by ourselves.

3.What products can you offer?

We’re one of the leading companies specializing in engineering machines, map folding machine, saddle stitching booklet maker machine, Digital Creaing machine, Gule binding machine, folding machine, pressure sealer, industry paper shredder, cardboard box shredder...etc.

4.How about the capacity of your company?

We have 12 modern types of energy-saving & environmentally-friendly production lines including a fully automated wax and shell making process flow line, as well as 4 heat treatment production lines. And our annual production capacity is over 20,000 tons.

5.How to guarantee the quality of your goods?

We will do the inspection after every process. For the finished products, we will do 100% inspection according to the customers’ requirements and the international standard.
