Description Video
Appearancetable mode
color white
work speed2speed
automatic paper length measurement
free Indentation
cover Identation
equal part Identation
binding Identation
operate display Color touch screen
display interfaceLCD
display definition standard definition
counting modepositive count
user mode(indentation data storage)32group
maximum feed size3200×600mm
minimum feed size140*140mm
creasing kinfe adapts to weight/thickness of paper 70-400g
perfoat knife adapts to weight/thickness of paper 150g~250g
paper type
paper feed modeair suction
feed directionCenter into the paper
feed table lengthening
feed table cappacity70mm
receive table capacity45mm
Indentation width gap1.0mm
Indentation direction Positive and negative are available
creasing /perforating precision 0.2mm
distance form the first mark to the paper hand1mm
creasing speed 4800sheets/hour(80sheets/min)
maximum number of creasing /perforating tracks32group
power supply220v/50hz
power  600W
power supply voltage adaptive range AC 200V-240V
net weight50KG
gross weight60KG
dimension in using1280×600×465mm
packing dimenstion580×660×620mm
easily replaceable extraction tool
high precision programmable indentation setting
standard corsswise dotted blade
option engthways dotted blade
automatic correction of paper deviation with differetn thickness
Indentation depth and skew adjustment
paper noise suction system X
large capacity feed table
automatic paper feed system




1.How long can i get the feedbacks after we sent the inquiry?

We will reply you within 12 hours in working day.

2.Are you a direct manufacturer or trading company?

We have two our own casting foundries and one CNC machining factory,we also have our own international sales department. We produce and sell all by ourselves.

3.What products can you offer?

We’re one of the leading company specialized in engineering machine , map folding machine , saddle stitching booklet maker machine , Digital Creaing machine, Gule binding machine , folding machine , pressure sealer , industry paper shredder, cardboard box shredder ...etc.

4.How about the capacity of your company?

We have 12 modern types of energy-saving & environmentally-friendly production lines including a fully automated wax and shell making process flow line, as well as 4 heat treatment production lines. And our annual production capacity is over 20,000 tons.

5.How to guarantee the quality of your goods?

We will do the inspection after every process.For the finished products,we will do 100% inspection according to the customers’ requirements and the international standard.
